LASCAR

USB Temperature Data Logger, LCD Screen, -35°C to +80°C, EL-USB-1-LCD

SKU:
EL-USB-1-LCD
Shipping:
Calculated at Checkout
$135.00 +GST

Stock Check

Description

This standalone data logger measures and stores up to 16,378 temperature readings over a -35 to +80°C (-31 to +176°F) range. The user can easily set up the logging rate and start-time, and download the stored data by plugging the data logger into a PC’s USB port and running the purpose designed software under Windows 2000, XP, Vista, and 7. Data can then be graphed, printed and exported to other applications. The high contrast LCD can show a variety of temperature information. At the touch of a button, the user can cycle between the current, maximum and minimum stored temperatures.

The data logger is supplied complete with a long-life lithium battery, which can typically allow logging for up to 1 year. The data logger is protected against moisture to IP67 standard when the protective cap is fitted.

Features:
USB Interface for Set-up and Data Download
User-Programmable Alarm Thresholds
Status Indication via Red and Green LEDs
Supplied with Replaceable Internal Lithium Battery and Windows Control Software
Environmental Protection to IP67

Model: EL-USB-1-LCD
Temperature Range: -35°C to +80°C
Internal Temperature Resolution: 0.5°C
Temperature Accuracy: 1°C
Minimum Logging Rate: Every 10 seconds until Memory is full
Maximum Logging Rate: Every 12 hours until Memory is full
Dimensions: 26mm dia x 98 length (mm)

View AllClose

Product Specifications

Pack Size:
1
